Der BricsCAD Communicator ist ein optionales Modul für BricsCAD Pro, BIM, Mechanik und Ultimate, das Unterstützung für hochwertigen 3D-Datenaustausch zwischen gängigen CAD-Formaten bietet. Er ermöglicht problemlose Arbeitsabläufe zwischen verschiedenen CAD-Werkzeugen im Maschinenbau. Importieren, bearbeiten, exportieren, zusammenarbeiten! Hochpräziser 3D-CAD-Import und -Export in Echtzeit. Der Communicator für BricsCAD importiert nicht nur nahtlos Geometrie-Daten, sondern auch PMI-Daten (Product Manufacturing Information) aus allen gängigen CAD-Anwendungen.
zum Download zum Angebot
Installieren sie zuerst BricsCAD Pro, Mechanik, BIM oder Ultimate. Installieren sie dann BricsCAD Communicator. Danach können Sie mit dem Befehlen IMPORT und EXPORT, die 3D-Daten im- und exportieren.
|

|
So starten Sie den BricsCAD Communicator
Wählen Sie in BricsCAD / Datei / Import oder Export.
Die unten gezeigte Fenster öffnen sich und Sie können die entsprechende Daten wählen.
|

|

|
Im- und Export-Formate
|
|
|
Import
|
Export
|
|
Windows
|
ACIS: .asab, .asat, .sab, .sat Autodesk Inventor: .iam, .ipt CATIA v4: .model CATIA v5/v6: .CATPart, .CATProduct, .CGR Creo Elements / Pro Engineer: .asm, .prt IGES: .iges, .igs NX: .prt Parasolid: .xmt_bin, .xmt_txt, .x_b, .x_t Siemens: .jt SolidWorks: .sldasm, .sldprt STEP: .step, .stp, .stpz VDA-FS: .vda XCGM: .xcgm
|
3D PDF: .pdf ACIS: .asab, .asat, .sab, .sat CATIA v4: .model CATIA v5: .CATPart, .CATProduct IGES: .iges, .igs STEP: .step, .stp VDA-FS: .vd XCGM: .xcgm
|
|
Linux
|
ACIS: .asab, .asat, .sab, .sat CATIA v4: .model Creo Elements / Pro Engineer: .asm, .prt IGES: .iges, .igs Parasolid: .xmt_bin, .xmt_txt, .x_b, .x_t Siemens: .jt Solid Edge: .asm, .par, .psm SolidWorks: .sldasm, .sldprt STEP: .step, .stp, .stpz VDA-FS: .vda XCGM: .xcgm
|
3D PDF: .pdf ACIS: .asab, .asat, .sab, .sat CATIA v4: .model IGES: .iges, .igs STEP: .step, .stp VDA-FS: .vd
|
|
Mac
|
ACIS: .asab, .asat, .sab, .sat CATIA v4: .model Creo Elements / Pro Engineer: .asm, .prt IGES: .iges, .igs Parasolid: .xmt_bin, .xmt_txt, .x_b, .x_t STEP: .step, .stp, .stpz VDA-FS: .vda
|
ACIS: .asab, .asat, .sab, .sat CATIA v4: .model IGES: .iges, .igs STEP: .step, .stp VDA-FS: .vd
|
Der STEP-Export als AP203, AP214 oder AP242 kann in BricsCAD mit Einstellungen / Einstellungen... / Communicator / Export 7 Step Optionen / Step Exportverions Format gesteuert werden. Sie können auch in die Eingabezeile von BricsCAD den Befehl EXPORTSTEPFORMATVERSION eingeben und bestätigen. Dabei ist 0=AP203 / 1=AP214 / 2=AP242.
|
